12 Straight Line Rip Saw – 15 HP 3 Ph 230460V – SLR12

• Full cast iron construction for rock-solid operation
• 15HP Main Motor, 2HP Feed Motor for large production capacity
• Auto-oiler with shut off ensures long conveyor chain life
• Seven pressure rollers with dual anti-kickback devices help prevent stock discharge
• Variable feed speeds to accommodate different type stock
• Large 18″ rip and 3-3/8″ depth of cut capacities for virtually any job
• Adjustable position control box for operator convenience
• Anti-Kickback Devices : 2
• Arbor Diameter (in) : 1
• Blade Diameter (in) : 12
• Blade Speed (RPM) : 4500
• Dust Collection Minimum CFM Required : 600
• Dust Port Diameter (OD/in) : 4
• Electric Controls – Magnetic Starter : 24V Magnetic
• Feed Motor HP : 2HP
• Feed Motor Phase : 3PH
• Feed Motor Volt : 230/460V (pre-wired 230V; 460V requires additional mag. switch purchase)
• Feed Speed (FPM) : 30-125 variable
• Height (in): 62
• Length (in): 41
• Maximum Depth of Cut (in) : 4
• Maximum Ripping Width (in) : 18
• Motor HP : 15HP
• Motor Phase : 3Ph
• Motor Voltage : 230/460V
• Net Weight : 2,090 pound
• Overall Dimensions : 62 x 56 x 41
• Part Number : 1791285
• Pressure Rollers : 7
• Prewired : Prewired 230V
• Shipping Dimensions (LxWxH/in) : 62 x 66 x 45
• Table Height (in) : 32
• Table Size (in) : 35 x 55
• Width (in): 56
• Shipping weight 2,530 lb.
